CE Certified, Safety Guaranteed
Has passed the CE safety certification (ISO 3691-4:2020) and other related certifications.
Smart Charging for Longer Battery Life
Monitors battery status in real time and dynamically optimizes the charging profile to maximize battery lifespan and performance.
Laser SLAM Navigation, Accuracy up to ±5 mm
Laser SLAM navigation offers a remarkable accuracy of ±5 mm and eliminates the need for reflectors during deployment.
Universal Rack Recognition
Recognizes a wide variety of racks and autonomously drives underneath to lift them, supporting diverse rack types across industries for greater application versatility.
Complete Software Ecosystem
Powered by SEER Robotics' integrated software suite, it enables factory-wide robot deployment, fleet scheduling, operation management, and data management. Seamlessly integrates with MES systems for streamlined end-to-end workflows.
Product Parameters
1000
Maximum Load Capacity (kg)1000
Maximum Load Capacity (kg)1000
Maximum Load Capacity (kg)
7
Comprehensive Battery Life (h)7
Comprehensive Battery Life (h)7
Comprehensive Battery Life (h)
1457.4
Rotation Diameter (mm)1457.4
Rotation Diameter (mm)1457.4
Rotation Diameter (mm)
2
Lidar Number2
Lidar Number2
Lidar Number
±5, ±1
Positioning Accuracy (mm,°)±5, ±1
Positioning Accuracy (mm,°)±5, ±1
Positioning Accuracy (mm,°)
≤1.5
Driving Speed (m/s)≤1.5
Driving Speed (m/s)≤1.5
Driving Speed (m/s)| Product model | SLR-1000EU |
| Product name | Laser SLAM Safety Lifting Robot |
| Navigation type | Laser SLAM |
| L x W x H | 1330 x 952 x 290.5 mm |
| Rotation diameter | 1457.4 mm |
| Weight (with battery) | 265 kg |
| Rated load | 1000 kg |
| Chassis ground clearance | 30.5 mm |
| Lifting platform dimensions | 1300 x 920 mm |
| Maximum lifting stroke | 60±1 mm |
| Navigation laser scanning height | 185 mm |
| Ambient temperature and humidity range | TEMP: 0℃ to 50℃ / RH: 10% to 90%, no compression, no condensation |
| Minimum aisle width | 1092 mm |
| Navigation position accuracy | ±5 mm |
| Navigation angle accuracy | ±1° |
| Driving speed | ≤1.5 m/s |
| Battery specifications | 48 V / 40 Ah (lithium iron phosphate) |
| Comprehensive battery life | 7 h |
| Charging time (10% to 80%) | ≤2 h |
| Charging method | Manual / Automatic |
| Lidar number | 2 |
| E-stop button | ● |
| Speaker | ● |
| Ambient lamp | ● |
| Bumper strip | ● |
| Basic functions | ● |
| Wi-Fi roaming | ● |
| Automatic charging | ● |
| Shelf recognition | ● |
| Laser reflector navigation | ○ |
| EMC | ● |
| UN38.3 | ● |
| MD | ● |
| RED | ● |
| Product model | SEER Lifting AMR |
